Arachnoids

Target Name:  Venus
Spacecraft:  Magellan
Produced by:  NASA/JPL
Copyright: NASA Copyright Free Policy

Related Document
Download Options

NameTypeWidth x HeightSize
arach.gifGIF511 x 463194K

Arachnoids are one of the more remarkable features found on Venus. They are seen on radar-dark plains in this Magellan image mosaic of the Fortuna region. As the name suggests, arachnoids are circular to ovoid features with concentric rings and a complex network of fractures extending outward. The arachnoids range in size from approximately 50 kilometers (29.9 miles) to 230 kilometers (137.7 miles) in diameter. Arachnoids are similar in form but generally smaller than coronae (circular volcanic structures surrounded by a set of ridges and grooves as well as radial lines). One theory concerning their origin is that they are a precursor to coronae formation. The radar-bright lines extending for many kilometers might have resulted from an upwelling of magma from the interior of the planet which pushed up the surface to form "cracks." Radar-bright lava flows are present in the 1st and 3rd image, also indicative of volcanic activity in this area. Some of the fractures cut across these flows, indicating that the flows occurred before the fractures appeared. Such relations between different structures provide good evidence for relative age dating of events. At present, arachnoids are found only on Venus and can now be more closely studied with the high resolution (120 meter/0.07 mile) radar imagery from Magellan.

This image is in the public domain and is copyright free.
