During its closest flyby of Saturn's wrinkled, icy moon Enceladus, Cassini obtained multi-spectral images of its cratered terrain that have been put together to create this false-color view.

To human eyes, Enceladus appears almost completely white, but false color reveals intriguing details. This view is a composite of images taken using filters sensitive to ultraviolet (centered at 338 nanometers), green (centered at 568 nanometers), and near-infrared (centered at 930 nanometers) light, and has been processed to accentuate subtle color differences. The uppermost surface of these terrains appears uniformly grey in this picture, suggesting that they are covered with materials of homogeneous composition and grain size. However, the walls of many of the fractures appear to be somewhat bluer than typical surface materials. It is possible that the difference in color identifies outcrops of solid ice on the walls of fractures, or ice with different grain-sizes, compared to powdery surface materials. It is also possible that the color identifies some compositional difference between buried ice and ice at the surface.

The surface is peppered with craters of all sizes, from the 21-kilometer (13-mile) diameter crater at the top of the image, down to tiny craters near the limit of resolution. The prominent crater at the top contains a central, domelike structure more than 11 kilometers (7 miles) in diameter. The dome, the crater--and indeed the entire scene--is sliced by a complex network of fractures ranging in width from hundreds of meters in some places, to over three kilometers (2 miles) in others.

The prominent, complex fracture in the bottom of the frame extends over 85 kilometers (53 miles) in length across the field of view. From Cassini's oblique vantage point, the walls of the large fracture are clearly visible. A pervasive network of narrow, parallel grooves can be seen in many places in the image, and they appear to slice the surface into parallel slabs of ice approximately 500 meters (1,600 feet) in thickness.

The image has been rotated so that north is at the top of the scene. The terrain in this scene is located on the side of Enceladus that faces away from Saturn, centered on latitude 28.7 north, longitude 192.5 west.

The image was taken during Cassini's closest-ever approach to Enceladus on March 9, 2005. It was taken with the Cassini spacecraft narrow-angle camera at a distance of approximately 21,300 kilometers (13,200 miles) from Enceladus and at a Sun-Enceladus-spacecraft, or phase, angle of 45 degrees. Resolution in the image is about 130 meters (430 feet) per pixel.
